12.5 Ton European Single Girder Wire Rope Hoist for Power Plant Workshop Lifting

Grande immagine : 12.5 Ton European Single Girder Wire Rope Hoist for Power Plant Workshop Lifting

Dettagli:

Luogo di origine:	Cina
Marca:	JCYC
Certificazione:	ISO9001,CE
Numero di modello:	SHSL

Termini di pagamento e spedizione:

Quantità di ordine minimo:	1 set
Prezzo:	USD4800-USD8000
Imballaggi particolari:	custodia in compensato
Tempi di consegna:	4 settimane
Termini di pagamento:	L/C,T/T,Western Union
Capacità di alimentazione:	15 set al mese

Contatto

Descrizione di prodotto dettagliata

Nome del prodotto:	Paranco europeo a fune metallica a trave singola da 12,5 tonnellate	Capacità di sollevamento:	12.5T
Altezza di sollevamento:	9-36 metri	Velocità di sollevamento:	Controllo dell'inventore
Velocità di corsa:	5-20 m/min, controllo dell'inventore	iso:	M5 M7
Tipo:	Monotrave o doppia trave

12.5 Ton European Single Girder Wire Rope Hoist for Power Plant Workshop Lifting

Product Introduction

European electric hoist is a popular lifting equipment for material handling. it is compact and lightweight, suitable for use in factories,warehouses, etc. As an ideal hoisting mechanism, it often matches with overhead cranes and gantry cranes. it needs the main beam to support the entire electric hoist and moves along the track. its electric motor provides power source for lifting tasks. Beside these parts, European hoist also has reducer, drum set, hook and electrical control system. There producer reduces the speed of the motor and increases the torque so European hoist could meet the needs of lifting heavy objects.

Key Specifications

Lifting capacity: 1-32t
Lifting height: 6-30m
Lifting speed: (0.8/5) m/min
Operating speed: (5-20) m/min
Power supply: 380V 50Hz 3P or Customized
Custom specifications available for different tonnage lifting heights and operational requirements

Advantage

Compact structure, light weight, low wheel pressure and high overall cost performance
Save operating costs and be low-carbon and environmentally friendly
Selected high-quality accessories, safe and reliable, durable
Precise positioning, efficient operation, and enhanced production efficiency
Safe and reliable, operation monitoring(optional), maintenance-free
Modular design with multiple options to meet the various working conditions of customers

Technical Specifications

Rated load S.W.L (Kg)	Work level	Lifting Height	Lifting speed	Traveling speed
SHSL-A	FEM	ISO	m	m/min	m/min
2000	1AM-4M	M3-M6	6/9/12/15/18	0.8/5	5~20
3200	1AM-4M	M3-M6	6/9/12/15/18	0.8/5	5~20
5000	1AM-4M	M3-M6	6/9/12/15/18	0.8/5	5~20
6300	1AM-4M	M3-M6	6/9/12/15/18	0.8/5	5~20
8000	1AM-4M	M3-M6	6/9/12/15/18	0.8/5	5~20
10000	1AM-4M	M3-M6	6/9/12/15/18	0.8/5	5~20
12500	1AM-3M	M3-M5	6/9/12/15/18	0.8/5	5~20
16000	1AM-3M	M3-M5	6/9/12/15/18	0.66/4	5~20
20000	1AM-3M	M3-M5	6/9/12/15/18	0.66/4	5~20

Main Components

Company Introduction

More Products

Company Certificate

Frequently Asked Questions

Q1. What types of cranes do you offer?

A1:as a manufacturer with over 15 years' experience, rui cheng provide a range of cranes,in cluding gantry cranes, overhead cranes, electric hoist, ib cranes, and customized lifting solutions tailoredto specific industry needs, such as for steel, precast concrete, and container handling

Q2. How do l know which crane is suitable for my project?

A2: Our team of experts is here to help! By understanding your lifting capacity requirements,operational environment, and usage freguency, we can recommend the ideal crane solution for your project.Contact us for a free consultation.

Q3. How to choose the right crane?

A3: The following factors need to be considered when choosing a crane: Load capacity, Lifting height Working environment, Frequency of operation.

Q4. What maintenance services do you offer?

A4: We offer comprehensive maintenance plans, including preventive maintenance,inspection, repairand spare parts replacement, to keep your crane running efficiently and safely. Our service teamis available forscheduled and emergency support.

Q5: Can you accept OEM?

A5: Yes, of course. Any logo is acceptable.Material, Color, Size, Packing, Brand, Delivery etc,

Q6:What are your delivery and installation timelines?

A6: Delivery and installation timelines vary based on the type and customization of the crane Generally, standard cranes can be delivered within 6-8 weeks, while customized solutions mayreauire additional time, We aim to provide accurate timelines upfront to ensure smooth proiec tplanning.

Q7: Do you offer installation services?

A7: Yes, we provide comprehensive training programs for crane operators, including safety trainingmaintenance guidelines, and operational best practices to ensure your team is fully prepared tooperate the crane safely and efficiently.
